Switch 24 porturi PoE RJ45 10G, 8 porturi SFP+ 10G, L2 Management, 1U - TP-Link Omada SX3832MPP

Tp-Link
14 316,72 RON (tartalmazza az ÁFÁ-t)
Tp-Link
Buy now, pay later tól 283,15 RON / Hónap Részletek
Ez a termék jelenleg nem érhető el. Szeretne értesítést kapni, amikor visszatér?
Livrare gratuita
Termék kód - SKU SX3832MPP
Hozzáadás a Kedvencekhez

Kiemelt termékek ugyanabból a kategóriából

Leírás

Switch-ul are urmatoarele caracteristici cheie:

  • 24× porturi 10 Gbps RJ45 si 8× sloturi 10 Gbps SFP+;
  • Buget PoE total de 770W si pana la 90W per port;
  • VLAN, ACL, QoS, IGMP Snooping, OAM si DDM;
  • Static Routing ajuta la redirectionarea traficului intern pentru o eficienta ridicata;
  • Managementul centralizat in cloud prin intermediul controller-ului Omada SDN;
  • Management independent prin web, CLI, SNMP si RMON.

Producator: TP-Link Omada
Numar porturi PoE: 24 x RJ45 10G
Capacitate switch: 640 Gbps
Alimentare: 100-240V AC
Temperatura operare: -5°C ~ +45°C
Dimensiuni: 440 mm x 330 mm x 44 mm 1U
Packet Forwarding Rate: 240 Mpps
MAC address table: 32K
Jumbo frame: 9 KB
Memorie flash: 32 MB
Memorie DRAM: 512 MB
Standarde: IEEE 802.3/u/ab/an/z/bz/ae/af/at/bt/x
Interfata consola: 1 x RJ45 1 x USB-C
Buffer: 24 MB
Consum: max. 953.7W
Porturi Uplink: 8 x SFP+ 10G
Putere PoE: max. 770W
"

Gyakran együtt vásárolt

Részletek

SKU
SX3832MPP
Kategóriák
Kapcsoló
Tömeg
5.7 kg
Márka
Tp-Link
Mounting brackets included
Yes
Packaging content
Console Cable
Rate limiting
Yes
Power over Ethernet (PoE)
Yes
Quality of Service (QoS) support
Yes
Jumbo frames support
Yes
MAC address table
32000 entries
Switching capacity
640 Gbit/s
Forwarding rate
240 Mpps
Packet buffer memory
24 MB
ARP inspection
Yes
Switch layer
L2+
Switch type
Managed
Multicast Listener Discovery (MLD) snooping
Yes
10G support
Yes
Heat dissipation
3444.7 BTU/h
Basic switching RJ-45 Ethernet ports type
10G Ethernet (100/1000/10000)
Installed SFP+ modules quantity
8
10G Ethernet (copper) ports quantity
24
Basic switching RJ-45 Ethernet ports quantity
24
Power source
AC/PoE
Power supply included
No
Total Power over Ethernet (PoE) budget
770 W
DHCP features
DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping
IGMP snooping
Yes
Authentication type
AAA, RADIUS, TACACS+
Jumbo frames
9
Stackable
Yes
Spanning tree protocol
Yes
Auto MDI/MDI-X
Yes
Link aggregation
Yes
2.5G Ethernet (copper) ports quantity
24
Cloud-managed
Yes
Multicast support
Yes
Auto-negotiation
Yes
Power over Ethernet (PoE) power per port
90 W
Access Control List (ACL)
Yes
Configuring Location Settings (CLI)
Yes
Number of VLANs
4000
Console port
RJ-45/USB Type-C
Fast Ethernet (copper) ports quantity
24
Gigabit Ethernet (copper) ports quantity
24
System event log
Yes
Port mirroring
Yes
Power over Ethernet 4PPoE (PoE++) ports quantity
24
Broadcast storm control
Yes
Authentication
Guest VLAN
Static port security
Yes
MIB support
RFC1213, RFC2233, RFC1643, RFC1493, RFC2674, RFC2819, RFC2021, RFC2620, RFC2618, RFC2925
IPv4 routes
48
Virtual LAN features
MVRP, Private VLAN, SSID-based VLAN assignment, VLAN Identifier ( VLAN ID), Voice VLAN
IPv6 routes
48
IPv4 & IPv6 features
Dual stack IPv4/IPv6, IPv6 SNMP, IPv6 SSH, IPv6 TFTP, IPv6 Telnet, IPv6 ping, IPv6 tracert
Firmware upgradeable
Yes
Rack mount kit
Yes
Rubber feet
Yes
Fanless
No
Queue scheduling algorithms
Strict Priority Queue (SPQ), WRR+SP, Weighted Round Robin (WRR)
Layer
Layer-2
Number of queues
8
Unified static configuration
Yes
Ethernet Ring Protection Switching (ERPS)
Yes
Address Resolution Protocol (ARP) entries (max)
510
Power saving mode (EEE)
Yes
Device link detection protocol (DLDP)
Yes
CPU defense
Yes
Sustainability organizations
Accountability
Screws included
Yes
Rack mounting
Yes
Web-based management
Yes
Static route
Yes
VLAN support
Yes
DoS attack prevention
Yes
Power consumption (typical)
953.7 W
Power consumption (max)
1010.2 W
AC input frequency
50/60 Hz
AC input voltage
110 - 240 V
Rackable
No
LAN-Port-Type
10Gigabit
Redundant-PSU
Yes
LAN-Ports
16
Width
440 mm
Cables included
Power
Depth
330 mm
Height
44 mm
LED indicators
Yes
Housing material
Metal
Operating temperature (T-T)
-5 - 45 C
Quick start guide
Yes
Product colour
Black
Storage temperature (T-T)
-40 - 70 C
Storage relative humidity (H-H)
5 - 90%
Compliance certificates
CE, Federal Communications Commission (FCC), RoHS
Form factor
DIN rail
Security algorithms
HTTPS, SNMP, SNMPv2, SNMPv3, SSH, SSL/TLS
Operating relative humidity (H-H)
10 - 90%
Number of fans
4 fan(s)
